Laser Engraving Machine-LaserBox (Education 2.0)

Item: LBOX-SDE2 Get Price In: Laser Engraving Machine Read: 1761 times

DESCRIPTION

Item Name: Smart Laserbox (Education 2.0)
Item No.: LBOX-SDE2
Laser tube type and power: CO₂ laser 40W
Working area: 500 × 300 mm
Z-axis height: 25mm
Locating system: Visual locating
Visual working area: 490 × 290 mm
Maximum cutting depth:15mm (Paulownia)
Autofocus: Material Recognition Autofocus, Material Set-up Autofocus, Visual Autofocus
Connection:Wi-Fi, USB, Ethernet
Design software:Photoshop, Illustrator, CorelDRAW, AutoCAD, AutoDraw, Solidworks, and etc.
File formats:JPG, PNG, BMP, TIF, DXF, SVG, CR2, and etc.
Operating systems: Windows, macOS
Material capability: Paper, corrugated paper, wood, acrylic, cloth, leather, base plate, ABS-based color board, PET, rubber, glass fiber, plastic, corian and other dozens of materials

Laserbox size: 1.07*0.63*0.43m (0.289/ 65KG)
4*Laserbox material : 0.31*0.17*0.23m (0.049/12kg)
Filter for laserbox: 0.68*0.28*0.22m 6kg (0.0419/6kg)
Smoke Purifier for Laserbox: 0.633*0.404*0.336m (0.086/15kg)

Details	Specification(Standard)
Laser System	CO2 Laser
Power	40W
Laser Cutting Machine Size:	958528268mm
Smoke Purifier Machine Size:	528260268mm
Working Area:	500*300mm
VisualizedWorkingArea	490*290mm
Maximum EngravableThickness	22mm
Range of Application	Cut & Engrave ● Wood board ● HB board ● Bamboo board ● Leather ● Paper ● Cardboard ● Acrylic ● Plastic ● Magnetic sticker Engrave Only ● Glass ● Marble ● Stone/Slate ● Coated Ceramic Tile ● Coated Aluminum
Laser Tube Life	10,000hours
Z AxisTravel	25mm
Maximum Speed	600mm/sec
Position Detection Accuracy	0.05mm
Maximum Cuttable Thickness	≤15mm Wood
Working Plate	Special surface that prevents burning
Cameras	500 million pixelsHD wide-angle camera
Cooling	Internal water coolingsystem
Autofocus	● Identifying material ● Setting thickness ● Visual identifying
Connection Method	Wi-Fi、USB、Internet
Position Detection Method	Computer vision detection
Focus Mode	Auto focus
Operating System	Windows、Mac OS ● Easy and powerful interface will have you printing in minutes ● Web interface works on Mac, PC, Linux, and many mobile devices (internet required) ● Compatible with JPG, PNG, SVG, PDF, and other file formats ● Drag-and-drop function and live camera preview to position designs on the material ● Automatically scan drawings and print without any design software ● Catalog of premium, customizable, ready-to-print designs
Compatible Software	Phtoshop, Ai, CorelDraw, AutoCAD, Solidworks
Firmware Upgrade Service	Only support firmware repair andupgrade service
Device Connection	One computer for simultaneous connections to several machines
Warranty	6 months
