BestSub Laserbox Realizes Every Idea with One Press on Button!



Are you looking for an ideal engraving & cutting machine? Then you can’t not miss our smart Laserbox. Let it guide you to know the magic of laser!

Laserboxis an intelligent tool for cutting and engraving, the essential machine for you to create with laser. It makes laser creation much easier! All you need to do is to design and leave all the rest of work to Laserbox. It can identify your design and the materials, and cut or engrave precisely and speedily according to your customization requirements. It features a visualized software interface and worktable through which you can watch your ideas coming to life.

Laserbox can cut and engrave various materials such as acrylic, wood and, leather, cloth and more. From advertising signs to home decors to personalized gifts, from hand drawing to graphic design to three-dimension work, it can realize all your creative ideas with laser!

Item Name: Laser Engraving Machine - LaserBox
Item No.: LBOX-SD
Weight: 82.2kg
Packing: 1set/ctn
Dimension: 2013*1204*996mm

Details

Specification(Standard)

Laser System

CO2 Laser

Power

40W

Laser Cutting Machine Size:

958*528*268mm

Smoke Purifier Machine Size:

528*260*268mm

Working Area:

500*300mm

VisualizedWorkingArea

490*290mm

Maximum EngravableThickness

22mm

Range of Application

Cut & Engrave

  • ●  Wood board
  • ●  HB board
  • ●  Bamboo board
  • ●  Leather
  • ●  Paper
  • ●  Cardboard
  • ●  Acrylic
  • ●  Plastic
  • ●  Magnetic sticker

Engrave Only

  • ●  Glass
  • ●  Marble
  • ●  Stone/Slate
  • ●  Coated Ceramic Tile
  • ●  Coated Aluminum

Laser Tube Life

10,000hours

Z AxisTravel

25mm

Maximum Speed

600mm/sec

Position Detection Accuracy

0.05mm

Maximum Cuttable Thickness

≤15mm Wood

Working Plate

Special surface that prevents burning

Cameras

500 million pixelsHD wide-angle camera

Cooling

Internal water coolingsystem

Autofocus

●  Identifying material

●  Setting thickness

●  Visual identifying

Connection Method

Wi-Fi、USB、Internet

Position Detection Method

Computer vision detection

Focus Mode

Auto focus

Operating System

Windows、Mac OS

  • ●  Easy and powerful interface will have you printing in minutes
  • ●  Web interface works on Mac, PC, Linux, and many mobile devices (internet required)
  • ●  Compatible with JPG, PNG, SVG, PDF, and other file formats
  • ●  Drag-and-drop function and live camera preview to position designs on the material
  • ●  Automatically scan drawings and print without any design software
  • ●  Catalog of premium, customizable, ready-to-print designs

Compatible Software

Phtoshop, Ai, CorelDraw, AutoCAD, Solidworks

Firmware Upgrade Service

Only support firmware repair andupgrade service

Device Connection

One computer for simultaneous connections to several machines

Warranty

6 months

2019 5 20 Laserbox
Features:

1. Leading market by qualified service;
2. Fashionable design with vivid sublimation printing effect;
3. Outstanding as personal gifts and promotional gifts or for commercial use;
4. Decades expertise;
5. One-stop service at BestSub.

Like BestSub on Facebook, Twitter, Youtube and Wechat.
For more information and free tutorial, please visit:www.bestsub.tv.
